README.md

Patch Panel

Please see entry.scad for config and building. Make sure the correct rack profile is configured in rackFrame.scad.

Mount RJ-45 keystone jacks with this part.
Single part. Can be printed without supports.

BOM:

Item	Name	Quantity	Comment
	M4x12 FHCS	4	Extras are useful and inexpensive. If you plan on eventually stacking multiple racks together, don't hesitate to get a lot more.
	M4 hex nut	4	☝️
